Palo Alto Firewall URL過濾 以及 Application Block Page

目錄

本篇文章將介紹Palo Alto防火牆針對封鎖URL以及第七層應用程式的限制功能,以下是主要的兩種功能:

  1. Application Block Page
  2. URL Filtering and Category Match Block Page

到Device→Response Pages找到Application Block Page,要確保是啟用的狀態

點選Application Block Page匯出預設的block頁面程式

匯出之後是一個txt的html檔案,可以編輯這個Block Page的html

<!DOCTYPE html>

<html lang="en">
<head>
    <base href="/login/">
    <meta charset="utf-8">
    <meta http-equiv="X-UA-Compatible" content="IE=edge">
    <meta name="viewport" content="width=device-width, initial-scale=.85">
    <meta http-equiv="pragma" content="no-cache">
    <title>Application Blocked</title>
    <link rel="stylesheet" href="css/latofonts.css">
    <style>
        body {
            background-color: #e8ebeb;
            font-family: Lato, 'Helvetica Neue', Helvetica, Arial, sans-serif;
            font-size: 16px;
            margin: 0;
            color: #070808;
        }

        a:link {
            color: #0993d1;
        }

        b,
        strong {
            font-weight: 500;
        }

        p {
            line-height: 1.2em;
        }

        button {
            overflow: visible;
        }

        button, input, optgroup, select, textarea {
            color: inherit;
            font: inherit;
            margin: 0;
        }

        .center {
            text-align: center;
            margin-left: auto;
            margin-right: auto;
        }

        #dError,
        .msg {
            color: #d94949;
            margin: 20px 0;
        }

        fieldset .msg {
            margin: 0;
        }

        #content {
            padding-top: 100px;
        }

        #content img {
            display: block;
            margin: auto;
        }

        #content h1 {
            font-style: normal;
            font-weight: normal;
            font-size: 36px;
            line-height: 43px;
            text-align: center;
            letter-spacing: 0.1px;
            color: #070808;
            margin: 10px auto 8px;
        }

        #content > p {
            text-align: center;
            margin-left: auto;
            margin-right: auto;
            width: 640px;
            font-size: 14px;
            line-height: 20px;
        }

        .response {
            background-color: #fff;
            color: #5a636b;
            margin: 24px auto 0;
            padding: 20px;
            font-size: 16px;
            width: 800px;
            border: 1px solid #c8cbce;
            box-sizing: border-box;
            border-radius: 8px;
        }

        .response p {
            margin: 0 0 1em;
        }

        .response p:last-child {
            margin: 0;
        }

        .response b {
            color: #070808;
        }

        .response .msg b {
            color: #d94949;
        }

        .response form td,
        .response form input {
            font-size: 1.1em;
            font-weight: bold;
        }

        .loading {
            margin: 2em auto 1em;
        }
    </style>
</head>

<body>
<div id="content" class="container">
    <h1>Against Acceptable Use Policy</h1>
    <div class="response">
        <p>The application you are trying to use has been blocked in accordance with company policy. Please contact your system administrator if you believe this is an error.</p>
	<img src="https://i.kym-cdn.com/entries/icons/original/000/002/144/You_Shall_Not_Pass!_0-1_screenshot.jpg" alt="blockImage" style="width:700px;height:600px;">
        <p><b>User:</b> <user/></p>
        <p><b>Application:</b> <appname/></p>
    </div>
</div>
</body>
</html>

最後我改成這樣

然後再放回PA的Block Page,點選Application Block Page→Import

之後這條就可以選擇你放進去的Block Page

然後URL Filtering and Category Match Block Page也做一樣的事情

Application Block Policy

到Policy→Security的頁面新增Block Policy,可以指定特定的,我是用any source到any destination,這邊我是用block application,針對facebook的所有功能

URL category就application-default就行

最後把facebook-base application給Deny掉

設定好之後就OK

URL Filtering Block Profile

到Objects→Security Profiles→URL Filtering,會有一個default的但不能編輯,所以我們clone default的那組,將其Export出來

然後我們編輯clone出來的profile,我們先把全部的category block掉,按Site Access→Set All Actions→block,就可以全部block掉

好了之後按下OK,之後再回到Policy新增一條針對URL Block的Policy
Policy→Security→Add

Source跟Destination我都先給any,Application除了block的之外都要給他通過

URL Category就用application-default的

而Action的部分除了URL Filtering要block的之外都允許通過,而Profile把URL Filtering的Block Policy放進來

好了之後按OK,把Policy的順序調一下,先把Block URL往前調,先block掉url,再block掉特定的application

Interface management

Network→Interfaces Mgmt

要確定Interface有開Response Pages才能顯示Block Page

並且確認出去的網卡是該Interface Management的

都確認完之後就可以測試

Policy Test

需要License才能測到Log,Application License過期不能Block,URL Filtering License過期不能Block
